European Journal of Chemistry 2011, 2(4), 524-534 | doi: https://doi.org/10.5155/eurjchem.2.4.524-534.438 | Get rights and content






  OPEN ACCESS | PEER-REVIEWED | RESEARCH ARTICLE | DOWNLOAD PDF | VIEW FULL-TEXT PDF | TOTAL VIEWS

A quick method for surveillance of 59 pesticide residues in fruits and vegetables using rapid three-dimensional gas chromatography (GC/MSD/µ-ECD/FPD) and LC/MS-MS


Gouri Satpathy (1) , Yogesh Kumar Tyagi (2,*) , Rajinder Kumar Gupta (3)

(1) University School of Basic and Applied Sciences, Guru Gobind Singh Indraprastha University, Sector 16 C, Dwarka, Delhi-110075, India
(2) University School of Basic and Applied Sciences, Guru Gobind Singh Indraprastha University, Sector 16 C, Dwarka, Delhi-110075, India
(3) University School of Biotechnology, Guru Gobind Singh Indraprastha University, Sector 16 C, Dwarka, Delhi-110075, India
(*) Corresponding Author

Received: 03 Apr 2011 | Revised: 16 May 2011 | Accepted: 23 May 2011 | Published: 31 Dec 2011 | Issue Date: December 2011

Abstract


This article describes a simple, quick and inexpensive method for determination of pesticides in fruits and vegetables. The method, known as the quick, easy, cheap, effective, rugged and safe (QuEChERS) method for pesticide residues, involves the extraction and simultaneous liquid-liquid partitioning formed by adding anhydrous magnesium sulfate (MgSO4) plus sodium acetate (NaAc) followed by a simple cleanup step known as dispersive solid-phase extraction (dSPE). The extracts were analyzed by three-dimensional gas chromatography GC/MSD/µ-ECD/FPD in trace ion mode and liquid chromatography/tandem mass spectrometry (LC/MS-MS). Method sensitivity, linearity, repeatability and reproducibility, accuracy, matrix effects, and overall uncertainties have been studied for method validation according to the international norm ISO/IEC: 17025:2005 for both techniques. Identification, quantification and reporting with Total and Extracted ion chromatograms, µECD and DFPD were facilitated to a great extent by Deconvolution Reporting Software (DRS) for GC and Mass hunter software for LC. For all compounds LODs were 0.001 to 0.01 mg/kg and LOQs were 0.005 to 0.020 mg/kg. Correlation coefficients of the calibration curves were >0.991. To validate the effects of matrices, repeatability, reproducibility, recovery and overall uncertainty were calculated for twenty-four matrices at 0.020, 0.050 and 0.500 mg/kg. Recovery ranged between 75-107 % with RSD <17 % for repeatability and intermediate precision and UM of ± 13-22 %.

2_4_524_534_800


Keywords


Fruits and vegetables; Pesticides; QuEChERS; Method validation; GC-MSD-µECD-DFPD; LC-MS/MS

Full Text:

PDF /    /


DOI: 10.5155/eurjchem.2.4.524-534.438

Links for Article


| | | | | | |

| | | | | | |

Related Articles




Article Metrics

This Abstract was viewed 1911 times | PDF Article downloaded 767 times

Funding information


Guru Gobind Singh Indraprastha University, Dwarka, Delhi-110075, India

Citations

/


[1]. Priscilla Porto-Figueira, Irene Camacho, José S. Câmara
Exploring the potentialities of an improved ultrasound-assisted quick, easy, cheap, effective, rugged, and safe-based extraction technique combined with ultrahigh pressure liquid chromatography-fluorescence detection for determination of Zearalenone in cereals
Journal of Chromatography A  1408, 187, 2015
DOI: 10.1016/j.chroma.2015.07.031
/


[2]. Yun-Wei Chang, Hien P. Nguyen, Mike Chang, S. Rebekah Burket, Bryan W. Brooks, Kevin A. Schug
Determination of nicotine and its metabolites accumulated in fish tissue using hydrophilic interaction liquid chromatography coupled with tandem mass spectrometry
Journal of Separation Science  38(14), 2414, 2015
DOI: 10.1002/jssc.201500235
/


References

[1]. Jaleel, C. A.; Gopi, R., Manivannan, P.; Panneerselvam, R. Pest Biochem. Physiol. 2008, 91, 170-174.
http://dx.doi.org/10.1016/j.pestbp.2008.03.006

[2]. Stoppelli, I. M.; Crestana, S. Environ. Int. 2005, 31, 731-738.
http://dx.doi.org/10.1016/j.envint.2005.02.002
PMid:15910970

[3]. Salameh, P.; Waked, M.; Baldi, I.; Brochard, P.; Saleh, B. A. J. Epidemiol. Community Health 2006, 60, 256-261.
http://dx.doi.org/10.1136/jech.2005.039677

[4]. The Prevention of Food Adulteration ACT, 1954 6th Edn. India, 2009.

[5]. Lehotaya, S. J.; Sonb, K. A.; Kwonb, H.; Koesukwiwata, U.; Fud, W.; Mastovskaa, K.; Hoha, E.; Leepipatpiboonc, N. J. Chromatogr. A 2010, 1217, 2548-2560.
http://dx.doi.org/10.1016/j.chroma.2010.01.044
PMid:20144460

[6]. Luke, M. A.; Froberg, J.E.; Masumoto, H. T. J. Assoc. Off. Anal. Chem. 1975, 58, 1020-1026.

[7]. Lee, S. M.; Papathakis, M. L.; Hsiao-Ming, C. F.; Carr, J. E. Fresenius J. Anal. Chem. 1991, 339, 376-383.
http://dx.doi.org/10.1007/BF00322352

[8]. Fillion, J.; Sauve, F.; Selwyn, J. J. AOAC Int. 2000, 83, 698-713.

[9]. Anastassiades, M.; Lehotay, S. J.; Štajnbaher, D.; Schenck, F. J. J. AOAC Int. 2003, 86, 412-431.

[10]. Lehotay, S. J.; Hiemstra, M.; van Bodegraven, P.; de Kok, A. J. AOAC Int. 2005, 88, 595-614.

[11]. Lehotay, S. J.; Mastovska, K.; Lightfield, A. R. J. AOAC Int. 2005, 88, 615-629.

[12]. Lehotay, S. J.; Mastovska, K.; Yun, S. J. J. AOAC Int. 2005, 88, 630-638.

[13]. Tomlin, C. D. S. The Pesticide Manual, 12th edn., The British Crop Protection Council, Farnham, Surrey, UK, 2000.

[14]. Guana, H.; Brewera, W.E.; Garrisb, S.T.; Morgana, S. L. J. Chromatogr. A 2010, 1217, 1867-1874.
http://dx.doi.org/10.1016/j.chroma.2010.01.047
PMid:20144461

[15]. Cook, J.; Beckett, M. P.; Reliford, B.; Hammack, W.; Engel, M. J. AOAC Int. 1999, 82, 1419-1435.

[16]. Mercer, G. E. J. AOAC Int. 2005, 88, 1452-1462.

[17]. Quimby, B.; Szelewski, M. Agilent Application Note 5989-4834EN, Wilmington, DE, 2006.

[18]. Etxebarria, N.; Zuloagaa, O.; Olivaresa, M.; Bartolomea, L.J.; Navarroa, P. J. Chromatogr. A 2009, 1216, 1624-1629.
http://dx.doi.org/10.1016/j.chroma.2008.12.038
PMid:19150537

[19]. Stajnbahera, D.; Zupancic-Kraljb, L. J. Chromatogr. A 2008, 1190, 316-326.
http://dx.doi.org/10.1016/j.chroma.2008.03.002
PMid:18367194

[20]. Mezcua, M.; Martinez-Uroz, M. A.; Wylie, P. L.; Fernandez-Alba, A. R. J. AOAC Int. 2009, 92, 1790-1806.

[21]. Norli, H. R.; Christiansena, A.; Holena, B. J. Chromatogr. A 2010, 13, 2056-2064.
http://dx.doi.org/10.1016/j.chroma.2010.01.022
PMid:20172528

[22]. Agnew, D.; Mata, N.; Weiner, K.; Wylie, P. Agilent Application Note 5968-3433E, Wilmington, DE, 1998.

[23]. Satpathy, G.; Tyagi, Y. K.; Gupta, R. K. Food Chem. 2011, 127, 1300-1308.
http://dx.doi.org/10.1016/j.foodchem.2011.01.087

[24]. Anastassiades, M.; Lehotay, S. J.; Stajnbher, D.; Schenk, F. J. J. AOAC Int. 2003, 86, 412-431.

[25]. Lehotay, S. J.; De Kok, A.; Hiemstra, M.; Van Bodegraven, P. J. AOAC Int. 2005, 88, 595-614.

[26]. Mastovska, K.; Lehotay, S. J.; Hajslova, J. J Chromatogr A 2001, 926, 291-308.
http://dx.doi.org/10.1016/S0021-9673(01)01054-8

[27]. NIST (2005), USA http://chemdata.nist.gov/massspc/amdis/index.html.

[28]. ISO guide to the expression of uncertainty in measurement (GUM: 1993)). BIPM, IEC, IFCC, ISO, IUPAC, IUPAP, OIML, Geneva.

[29]. Dagan, S. J. Chromatogr. A 2000, 868, 229-247.
http://dx.doi.org/10.1016/S0021-9673(99)01138-3

[30]. Wylie, P. L.; Szelewski, M. J.; Meng, C. Agilent Application Note 5989-1157EN, Wilmington, DE, 2004.

[31]. ICH-Topic Q2b. (1996). Guidance for industry-Validation of analytical procedures: Methodology. U.S. Department of Health and Human Services.

[32]. Chai, M. K.; Tan, G. H. Food Chem. 2009, 117, 561-567.
http://dx.doi.org/10.1016/j.foodchem.2009.04.034

Supporting information


The Supplementary Material for this article can be found online at: Supplementary files

How to cite


Satpathy, G.; Tyagi, Y.; Gupta, R. Eur. J. Chem. 2011, 2(4), 524-534. doi:10.5155/eurjchem.2.4.524-534.438
Satpathy, G.; Tyagi, Y.; Gupta, R. A quick method for surveillance of 59 pesticide residues in fruits and vegetables using rapid three-dimensional gas chromatography (GC/MSD/µ-ECD/FPD) and LC/MS-MS. Eur. J. Chem. 2011, 2(4), 524-534. doi:10.5155/eurjchem.2.4.524-534.438
Satpathy, G., Tyagi, Y., & Gupta, R. (2011). A quick method for surveillance of 59 pesticide residues in fruits and vegetables using rapid three-dimensional gas chromatography (GC/MSD/µ-ECD/FPD) and LC/MS-MS. European Journal of Chemistry, 2(4), 524-534. doi:10.5155/eurjchem.2.4.524-534.438
Satpathy, Gouri, Yogesh Kumar Tyagi, & Rajinder Kumar Gupta. "A quick method for surveillance of 59 pesticide residues in fruits and vegetables using rapid three-dimensional gas chromatography (GC/MSD/µ-ECD/FPD) and LC/MS-MS." European Journal of Chemistry [Online], 2.4 (2011): 524-534. Web. 6 Aug. 2020
Satpathy, Gouri, Tyagi, Yogesh, AND Gupta, Rajinder. "A quick method for surveillance of 59 pesticide residues in fruits and vegetables using rapid three-dimensional gas chromatography (GC/MSD/µ-ECD/FPD) and LC/MS-MS" European Journal of Chemistry [Online], Volume 2 Number 4 (31 December 2011)

The other citation formats (EndNote | Reference Manager | ProCite | BibTeX | RefWorks) for this article can be found online at: How to cite item


DOI Link: https://doi.org/10.5155/eurjchem.2.4.524-534.438

| | | | | | |

| | | | | |

Save to Zotero Save to Mendeley
