The use of calixarene as ionophores in potentiometric ion-selective electrodes of naftidrofuryl oxalate using microsized membrane sensors for kinetic study of naftidrofuryl (NFT) degradation

Main Article Content

Mohammad Abdalla El-Sayed


Novel miniaturized polyvinyl chloride membrane sensors in all-solid state graphite and platinum wire supports were developed, electrochemically evaluated and used for the assay of naftidrofuryl oxalate. The naftidrofuryl oxalate sensors were based on the formation of an ion-association complex between the drug cation and tetrakis-(4-chlorophenyl)borateanionic exchanger as electroactive material and sulfocalix-8-arene as ionophore dispersed in a polyvinyl chloride matrix. Linear responses of 10-2-10-6 M and 10-2-10-5 M with cationic slopes of 56.9 mV and 54.1 mV over the pH range 2-5 were obtained by using the naftidrofuryl oxalate-coated graphite (Sensor 1) and platinum wire (Sensor 2) membrane sensors, respectively. The utility of 4-sulfocalix-8-arene as ionophore had a significant influence on increasing the membrane sensitivity and selectivity. The methods were also used to determine the intact drug in the presence of it’s degradate in Praxilene® tablets, plasma and cerebrospinal fluid with good recovery. Sensor 1 was used to study the kinetics of naftidrofuryl oxalate alkaline degradation that was found to follow a pseudo first-order reaction. The activation energy could be estimated from the Arrhenius plot to be 12.572 Kcal/mol.


icon graph This Abstract was viewed 1561 times | icon graph Article PDF downloaded 2027 times

How to Cite
El-Sayed, M. A. The Use of Calixarene As Ionophores in Potentiometric Ion-Selective Electrodes of Naftidrofuryl Oxalate Using Microsized Membrane Sensors for Kinetic Study of Naftidrofuryl (NFT) Degradation. Eur. J. Chem. 2013, 4, 124-131.

Article Details

Crossref - Scopus - Google - European PMC

[1]. The Merck index, 14th Ed.; Merck Research laboratories, White house station, 2006.

[2]. Martindale, The Complete Drug Reference, 37 thEd.; Pharmaceutical Press, London, 2011.

[3]. British Pharmacopeia, Her Majesty's Stationary office, London, 2009.

[4]. Belal, T. S.; Barary, M. H.; Sabry, S. M.; Abdel-Latif, M. E. Food Drug Anal. 2009, 17(6), 415-423.

[5]. Sabry, S. M.; Belal, T. S.; Barary, M. H.; Ibrahim, M. E. A. Int. J. Biomed. Sci. 2009, 5(3), 283-292.
PMid:23675149 PMCid:3614792

[6]. Hosny, M. M.; Ayad, M. M.; Abdellatef, H. E.; Sharaf, Y. A. Anal. Chem. (An indian journal) 2011, 10(6), 400-408.

[7]. Abbas, S. S.; Zaazaa, H. E.; El-Ghobashy, M. R.; Fayez, Y. M.; Omar, S. A. Anal. Chem. (An indian journal) 2012, 11(11,12), 329-334.

[8]. Brodie, R. R.; Chasseaud, L. F.; Taylor, T. J. Chromatogr. Biomed. 1979, 164(4), 534-540.

[9]. Garrett, E. R.; Barbhaiya, R. J. Pharm. Sci. 1981, 70(1), 39-45.

[10]. Walmsley, L. M.; Wilkinson, P. A.; Brodie, R. R; Chasseaud, L. F. J. Chromatogr. Biomed. 1985, 338, 433-437.

[11]. Stehlik, P.; Houbova, H. Cesk. Farm. 1990, 39, 394-399.

[12]. Waaler, P. J.; Mülle, B. W. Int. J. Pharm. 1992, 87(1-3)(10), 223-227.

[13]. Abbas, S. S.; Zaazaa, H. E.; El-Ghobashy, M. R.; Fayez, Y. M.; Omar, S. A. Anal. Chem. (An indian journal) 2012, 8(4), 613-620.

[14]. Sabry, S. M.; Belal, T. S.; Barary, M. H.; Abdel-Latif, M. E. Drug Test. Anal. 2012, doi: 10.1002/dta.421

[15]. Koppenhoefer, B.; Jakob, A.; Zhu, X. F.; Lin, B. C. High. Resol. Chromatogr. 2000, 23(6), 413-429.<413::AID-JHRC413>3.0.CO;2-E

[16]. Wang, F.; Dowling, T.; Bicker, G.; Wyvratt, J. J. Sep. Sci. 2001, 24(5), 378-384.<378::AID-JSSC378>3.0.CO;2-M

[17]. Zhong, W. W.; Yeung, E. S. Electrophoresis 2002, 23(17), 2996-3005.<2996::AID-ELPS2996>3.0.CO;2-8

[18]. Munoz-de-la-Pena, A.; Espinosa-Mansilla, A.; Murillo-Pulgarin, J. A.; Alanon-Molina, A.; Fernandez-Lopez, P. Analyst (Cambridge, UK) 1998, 123(11), 2285-2290.

[19]. Murillo-Pulgarin, J. A.; Alanon-Molina, A.; Fernandez-Lopez, P. Anal. Chim. Acta 1999, 382(1-2), 77-85.

[20]. Segura-Carretero, A.; Cruces-Blanco, C.; Canabate-Diaz, B.; Fernandez-Sanchez, J. F.; Fernandez-Gutierrez, A. Anal. Chim. Acta. 2000, 417(1), 19-30.

[21]. Cruces-Blanco, C.; Segura-Carretero, A.; Fernandez-Sanchez, J. F.; Fernandez-Gutierrez, A. J. Pharmaceut. Biomed. Anal. 2000, 23(5), 845-850.

[22]. Fernandez-Sanchez, J. F.; Segura-Carretero, A.; Cruces-Blanco, C.; Fernandez-Gutierrez, A. Anal. Chim. Acta 2002, 462(2) 217-224.

[23]. Li, W.; Cao, L. X.; Li, G. R.; Jin, W. J. Guangpuxue-Yu-Guangpu. Fenxi 2002, 22, 518-522.

[24]. Ionescu, M. S, Badea, V.; Baiulescu, G. E.; Cosofret, V. V. Talanta 1986, 33(1), 101-103.

[25]. Abbas, S. S.; Zaazaa, H. E.; El-Ghobashy, M. R.; Fayez, Y. M.; Omar, S. A. Port. Electr. Acta 2012, 30(3), 177-188.

[26]. Park, S. J.; Shon, O. J.; Rim, J. A.; Lee, J. K.; Kim, J. S.; Nam, H.; Kim, H. Talanta 2001, 55, 297-304.

[27]. Kumar, P.; Shim, Y. B. Talanta 2009, 77, 1057-1062.

[28]. Kivlehan, F.; Mace, W. J. Moynihan, H. A.; Arrigan, D. W. M. Anal. Chim. Acta 2007, 585, 154-160.

[29]. Bakker, E.; Qin, Y. Anal. Chem. 2006, 78, 3965-3984.
PMid:16771535 PMCid:2883720

[30]. Chen, L.; Zhang, J.; Zhao, W.; He, X.; Liu, Y. J. Electroanal. Chem. 2006, 589, 106-119.

[31]. Zareh, M.; Malinowska, B. J. AOAC Int. 2007, 90, 147-152.

[32]. El-Kosasy, A. M.; Nebsen, M.; Abdelrahman, M. K.; Salem, M. Y.; El-Bardicy, M. G. Talanta 2011, 85, 913-918.

[33]. Belal, F.; Metwaly, F. H.; Younes, K. M.; Amer, S. M. Port. Electr. Acta 2009, 27(4), 463-475.

[34]. Shamsipur, M.; Mizani, F.; Mousavi, M. F.; Eshghi, H.; Karami, H. Anal. Chim. Acta 2007, 589, 22-32.

[35]. Koudelka-Hep, M.; Van-der-Wal, P. D. Electrochimica Acta 2000, 45, 2437-2441.

[36]. Ji, X.; Jin, B.; Ren, J.; Jin, J.; Nakamura, T. J. Electroanal. Chem. 2005, 579, 25-31.

[37]. Peng, W.; Wang, E. Anal. Chim. Acta 1993, 281, 663-671.

[38]. James, H.; Carmack, G.; Freiser, H. Anal. Chem. 1972, 44, 856-857.

[39]. Ibrahim, H.; Issa, Y. M.; Abu-Shawish, H. M. J. Pharmaceut. Biomed. Anal. 2007, 44, 8-15.

[40]. Abbaspour, A.; Zadyar, A.; Sharghi. H. Anal. Chim. Acta 2004, 525, 91-96.

[41]. Lockridge, J. E.; Fortier, N. E.; Schmuckler, G.; Fritz, J. S. Anal. Chim. Acta 1987, 192, 41-48.

[42]. Cervini, P.; Ramos, L. A.; Cavalheiro, E. G. Talanta 2007, 72, 206-209.

[43]. Bouklouze, A. A.; El-Jammal, A.; Vire, J. C.; G. J. Patriarche, G. J. Anal. Chim. Acta 1992, 257, 41-48.

[44]. El-Kosasy, A. M.; Salem, M. Y.; El-Bardicy, M. G.; Abdelrahman, M. K. Chem. Pharm. Bull. 2008, 56, 753-757.

[45]. El-Sayed, M. A. Talanta 2011, 83, 717-723.

[46]. Hassan, S. S.; Amer, M. M.; Abd. El-Fattah, S. A.; El-Kosasy, A. M. Talanta 1998, 46, 1395-1406.

[47]. Nebsen, M.; Abd El-Rahman, M. K.; El-kosasy, A. M.; Salem, M. Y.; El-Bardicy, M. G. Port. Electr. Acta 2011, 29(3), 165-176.

[48]. IUPAC, Analytical Chemistry Division, Commission on Analytical Nomenclature, Pure Appl. Chem. 2000, 72, 1851.

[49]. Mittal, S. K.; Kumar, A.; Gupta, N.; Kaur, S.; Kuma, S. Anal. Chim. Acta 2007, 585, 161-170.

[50]. Zanganeh, A. R.; Amini, M. K. Sens. Actuat. B: Chem. 2008, 135, 358-365.

[51]. Gorski, L.; Matusevich, A.; Parzuchowski, P.; Luciuk, I.; Malinowska, E. Anal. Chim. Acta 2010, 665, 39-46.

[52]. Kaliappan, R.; Ling, Y.; Kaifer, A. E.; Ramamurthy, V. Langmuir 2009, 25, 8982-8992.

[53]. Vyza, E. A.; Buckton, G.; Michaleas, S. G.; Loukas, Y. L.; Efentakis, M. Int. J. Pharm. 1997, 158, 233-238.

[54]. Florence, A. T.; Attwood. D. Physical Principles of Pharmacy, 2nd edition, Macmillan Press, 1998.

[55]. Martin, A.; Swarbrick, J.; Cammarata. A. Physical Pharmacy, 3rd edition, Lea; Febiger (Philadelphia) USA, 1983, 359-360.

[56]. Pilling, M. J.; Seakins, P. W. Reaction kinetics, Oxford science publications, 2nd edition, New York, 1995, pp. 8-10.

[57]. Loyd V. Allen, REMINGTON, The Science; Practice of Pharmacy, Lippencott Williams & Willkens, Easton, Pennsylvania, 19th edition, 1995, p. 116.
